產品特性 Characteristic
減速機構 Reduction Mechanism
- 通過凸輪使薄壁軸承、柔性齒輪呈橢圓狀變形。
- 柔性齒輪與內齒輪在橢圓形長軸部分發生嚙合。
- 固定內齒輪，使凸輪沿順時針方向旋轉 360°時，柔性齒輪會沿逆時針方向移動內齒輪與柔性齒輪的齒數差部分。
規 格 表
| 機型 TYPE |
比數 RATIO |
背隙 ( arcmin ) Backlash |
額定輸出扭矩 ( Nm ) Rated Output Torque |
平均負載最大轉矩 ( Nm ) Max. Output Torque |
起動停止峰值轉矩 ( Nm ) Emergency Stop Starting Torque |
起動轉矩 (cNm) Starting Torque |
增速啟動轉矩 ( Nm ) Output Starting Torque |
無負載運轉力矩(cNm) No-load Running Torque |
額定輸入轉速 (rpm) Nominal Input Speed | 最大輸入轉速 (rpm) Max. Input Speed | 慣性力矩 (Ix10-4kgm2)Reducer Inertia |
|---|---|---|---|---|---|---|---|---|---|---|---|
| DSF14-S DSG14-S |
50 | less than 1 | 7 | 9 | 21 | 4 | 1.5 | 4 | 2,000 | 6,000 | 0.04 |
| DSF14-S DSG14-S |
80 | less than 1 | 9 | 13 | 27 | 3 | 1.6 | 3 | 2,000 | 6,000 | 0.04 |
| DSF14-S DSG14-S |
100 | less than 1 | 9 | 13 | 32 | 2.5 | 1.7 | 2 | 2,000 | 6,000 | 0.04 |
| DSF17-S DSG17-S |
50 | less than 1 | 20 | 32 | 42 | 6 | 2.6 | 5 | 2,000 | 6,000 | 0.08 |
| DSF17-S DSG17-S |
80 | less than 1 | 27 | 33 | 53 | 4 | 2.7 | 4 | 2,000 | 6,000 | 0.08 |
| DSF17-S DSG17-S |
100 | less than 1 | 29 | 48 | 67 | 3.5 | 2.8 | 3 | 2,000 | 6,000 | 0.08 |
| DSF17-S DSG17-S |
120 | less than 1 | 29 | 48 | 67 | 3 | 2.9 | 3 | 2,000 | 6,000 | 0.08 |
| DSF20-S DSG20-S |
50 | less than 1 | 30 | 40 | 66 | 8 | 4.1 | 7 | 2,000 | 6,000 | 0.2 |
| DSF20-S DSG20-S |
80 | less than 1 | 40 | 55 | 86 | 5 | 4.2 | 6 | 2,000 | 6,000 | 0.2 |
| DSF20-S DSG20-S |
100 | less than 1 | 47 | 58 | 96 | 4 | 4.3 | 5 | 2,000 | 6,000 | 0.2 |
| DSF20-S DSG20-S |
120 | less than 1 | 47 | 58 | 102 | 4 | 4.5 | 4 | 2,000 | 6,000 | 0.2 |
| DSF25-S DSG25-S |
50 | less than 1 | 45 | 64 | 112 | 15 | 8.2 | 12 | 2,000 | 5,000 | 0.4 |
| DSF25-S DSG25-S |
80 | less than 1 | 72 | 99 | 157 | 9 | 8.4 | 10 | 2,000 | 5,000 | 0.4 |
| DSF25-S DSG25-S |
100 | less than 1 | 77 | 123 | 180 | 8 | 8.6 | 8 | 2,000 | 5,000 | 0.4 |
| DSF25-S DSG25-S |
120 | less than 1 | 77 | 123 | 191 | 7 | 8.8 | 7 | 2,000 | 5,000 | 0.4 |
| DSF32-S DSG32-S |
50 | less than 1 | 90 | 127 | 225 | 32 | 17 | 28 | 2,000 | 5,000 | 1.7 |
| DSF32-S DSG32-S |
80 | less than 1 | 138 | 195 | 316 | 20 | 18 | 20 | 2,000 | 5,000 | 1.7 |
| DSF32-S DSG32-S |
100 | less than 1 | 160 | 253 | 346 | 18 | 19 | 18 | 2,000 | 5,000 | 1.7 |
| DSF32-S DSG32-S |
120 | less than 1 | 160 | 253 | 367 | 15 | 20 | 14 | 2,000 | 5,000 | 1.7 |
| DSF40-S DSG40-S |
50 | less than 1 | 140 | 200 | 350 | 55 | 29 | 48 | 2,000 | 4,000 | 4.5 |
| DSF40-S DSG40-S |
80 | less than 1 | 209 | 288 | 452 | 35 | 30 | 30 | 2,000 | 4,000 | 4.5 |
| DSF40-S DSG40-S |
100 | less than 1 | 261 | 377 | 494 | 32 | 32 | 26 | 2,000 | 4,000 | 4.5 |
| DSF40-S DSG40-S |
120 | less than 1 | 298 | 457 | 537 | 28 | 34 | 25 | 2,000 | 4,000 | 4.5 |
